Models               KNIK-0.5GC-2  KNIK-1GC-2     KNIK-2GC-2     KNIK-3GC-2    KNIK-5GC-2    KNIK- 7GC-2    KNIK-10GC-2
working Volume  0.2-0.4L          0.5- 0.7 L        1–1.4 Liter      1.5-2L            2.5-3.5L          3.5-5 L            5- 7 l
Load Proportion 65-80% of total volume, 70% optimum
Vessel Material glass body and stainless steel lid

The high ratio: 2:1

Mixing method:  Magnetic Drive from bottom, without mechanical seal
Sterilization method: off-site sterilization  Autoclavable

Control system: Siemens PLC, industrial LCD touch computer control, parameters can be set to store, can be remotely connected to the computer through the USB interface, the data

Stirring system
high-powered stirring oar, antifoam oar; AC electrical machine: infinite speed variation; rpm in the fermenter: 70~1２00rpm±1%,The height of the stirring oar can be adjusted, too.

Temperature detection and control
Heat by thermostatic water tank and circulate by circulating pump(Grundfos, Denmark), autocontrol (cooling water+5℃)~65℃±0.1℃，temperature probe(US)

pH detection and control
2.00-12.00±0.05pH, autocontrol by adding acid and base, pH sensor (Mettler, Switzerland) and shielding lead (Mettler, Switzerland). fermenter is autocontrolled with peristaltic pump

DO detection and control
0-150±3% displaying precision 0.1%, sensor (Mettler, Switzerland) and shielding lead(Mettler, Switzerland)

Feed control
fermenter uses peristaltic pump (Longer) to add meterials

Antifoam control
Tested by sencor and added antifoamer by peristaltic pump

Intake control (air) :manual control rotameter

pressure detection and control
Pressure Control: Pressure meter and digital display and digital remote control, pressure control

Automatic cleaning (CIP)
Automatic sterilisation (SIP)
High throughput
Easiest operation
Robust, proven technology
Small footprint
Cost-saving
